1.1 The machine take the HDPE or LDPE as raw material, through heating, extrusion, blowing, stretch, winder and final be roll thin film. 1.2 The finished plastic thin film is widely used for supermarket bag, garbage bag, various plastic package bag, farmland film.cote film and compound thin film.
XJBXJ-A50-600 PE Film Blowing Extrusion Machine
Feature:
1.1 The machine take the HDPE or LDPE as raw material, through heating, extrusion, blowing, stretch, winder and final be roll thin film.
1.2 The finished plastic thin film is widely used for supermarket bag, garbage bag, various plastic package bag, farmland film.cote film and compound thin film.
Model |
A50-600 |
Screw Diameter |
50mm |
Screw Ratio |
29:1 |
Screw Speed |
10-110r/min |
Max. Output |
10-35kg/h |
Max. Folding Width of Film |
600mm |
Thickness of Film |
0.008-0.10mm |
Main Motor |
11Kw |
Total Power |
26Kw |
Average power consumption |
13kw/h |
Weight of Machine |
1800kg |
Overall Dimensions |
4.2×2.1×4.2m |
1.Q:Are you machinery factory or trading company?
Answer: All the machines buy from our company guarantee is one year (except any human mistake occurred) each machines we will give some spare parts free when shipping machines. Within guarantee machine parts damage, we will send to you free by express asap. If customer required engineer go to solve problem is possible.
